• Fully Digital, twin DSP controlled

• Rated at 0.9 output power factor to deliver more active power

• Handle leading power factor loads without KW derating under specified conditions

• On-Line Double Conversion IGBTbased PWM Inverter

• Wide input voltage tolerance (+20/-20%)

• Wide input frequency range of 45Hz to 65Hz

• High overload capability of static bypass (14 times for 10 milliseconds and 10 times for 100 milliseconds)

• Capability to handle: High crest factor loads 100% non-linear loads 100% unbalanced loads

• Built-in maintenance bypass Front access for spares replacement and preventive maintenance

• Easy Dual bus configuration architecture

• Adjustable frequency synchronization window up to 6% in the static bypass

• Field protocols ModBus / Jbus

• Network protocols SNMP

• Overload capability of the UPS: 110% full load for 60 minutes 125% full load for 10 minutes 150% full load for 1 minutes

• Compact footprint
